Manual Folding Booms



     10,13,16,20 ft Closed Boom                  10,13,16,20 ft Open Boom                             27 ft Boom

                Closed Dry Boom.jpg (120557 bytes)                       Open Dry Boom.jpg (78241 bytes)                     Export 27 ft open.jpg (229614 bytes)

                        (Click on thumbnails to view bigger picture)

Description:  The manual folding boom is a spring-loaded boom.  It is available in 5 different sizes: 10ft, 13ft, 16ft, 20ft and 27ft.  The booms structure is made of galvanized square steel.  All our folding booms are boxed and can be shipped by carrier such as UPS.  Nozzles and nozzle body are not included.

Cross-section dimension:   center section is 1 1/4" x  1 1/4"

                                                  wing section is 1" x 1"

Table:  Part Numbers for Manual Folding Booms

Open Boom LengthHinge to Hinge LengthWeightBox DimensionDry Boom Part Number
10 ft36 in22 lbs65" x 8" x 8"BG017460
13 ft48 in25 lbs65" x 8" x 8"GG100499000F
16 ft61 in31 lbs65" x 8" x 8"BG005454
20 ft74 in38 lbs78" x 8" x 8"GG100699000F
27 ft74 in 55 lbs78" x 7" x 15"BG001443Z1

Click here to request price on the Manual Folding Boom product.
